The MSSP module has a Baud Rate Generator available for clock generation in both I2C and SPI Master modes. The Baud Rate Generator (BRG) reload value is placed in the SSPADD register (Register 21-6). When a write occurs to SSPBUF, the Baud Rate Generator will automatically begin counting down.

Once the given operation is complete, the internal clock will automatically stop counting and the clock pin will remain in its last state. An internal signal “Reload” in Below Figure triggers the value from SSPADD to be loaded into the BRG counter when Extract Embedded Microcontroller PIC18F2682 Code.

This occurs twice for each oscillation of the module clock line. The logic dictating when the reload signal is asserted depends on the mode the MSSP is being operated in. Below Table demonstrates clock rates based on instruction cycles and the BRG value loaded into SSPADD.

The I2C interface does not conform to the 400 kHz I2C specification (which applies to rates greater than 100 kHz) in all details, but may be used with care where higher rates are required by the application of Microchip PIC16F1783 Memory Program Extraction.

bit 7 SMP: SPI Data Input Sample bit SPI Master mode:

1 = Input data sampled at end of data output time

0 = Input data sampled at middle of data output time SPI Slave mode:

SMP must be cleared when SPI is used in Slave mode

In I2C Master or Slave mode:

1 = Slew rate control disabled for standard speed mode (100 kHz and 1 MHz)

0 = Slew rate control enabled for high speed mode (400 kHz) bit 6 CKE: SPI Clock Edge Select bit (SPI mode only) in order to Read Locked Microcontroller PIC18F2680 Software

In SPI Master or Slave mode:

1 = Transmit occurs on transition from active to Idle clock state

0 = Transmit occurs on transition from Idle to active clock state In I2C™ mode only:

1 = Enable input logic so that thresholds are compliant with SMbus specification

0 = Disable SMbus specific inputs

bit 5 D/A: Data/Address bit (I2C mode only)

1 = Indicates that the last byte received or transmitted was data from MCU Crack

0 = Indicates that the last byte received or transmitted was address bit 4 P: Stop bit

(I2C mode only. This bit is cleared when the MSSP module is disabled, SSPEN is cleared.)

1 = Indicates that a Stop bit has been detected last (this bit is ‘0’ on Reset)

0 = Stop bit was not detected last

bit 3 S: Start bit

(I2C mode only. This bit is cleared when the MSSP module is disabled, SSPEN is cleared.) to carry out the Encrypted Chip PIC18F2620 Heximal Copy

1 = Indicates that a Start bit has been detected last (this bit is ‘0’ on Reset)

0 = Start bit was not detected last
